SPECIFICATION

FRAME: 100% Chromoly tubes, removable brake mounts, integrated seat clamp, compact 5mm dropout, sealed Mid bottom bracket

STEERING 9” Chromoly handlebars, Stratos OE stem, flangeless TEAM grips w/ Vortex barplugz, sealed integrated headset, tapered Chromoly fork w/ one-piece steerer

DRIVE: 25x9t, sealed hubs w/ double wall Revolver rims, STLN 20x2.2”/2.3” tires, 170mm Chromoly 48 spline cranks, Alloy sprocket, Thermalite pedals

SEATING: Kushion Kevlar top Pivotal seat, 150mm Thermalite seatpost

COLOR: Matte Alloy Silver w/ Anodize Blue -or- Matte Black

WEIGHT: 24.2 lbs. (w/o brakes)

UPGRADES OVER "HEIST"

• 100% Chromoly frame

• Removable brake hardware

• Left-hand drive option

• Chromoly 48 spline cranks

• Aftermarket Kushion Pivotal seat

• Aftermarket Thermalite Pivotal post

GEOMETRY

75° Head Tube | 21” Top Tube | 71° Seat Tube | 13.5” Chain Stay

8.7” ST Height | 11.75“ BB Height | 9” Bar Height | 28mm Fork Offset

Please note all bikes come boxed with instructions and need to be partly built up.
